Western Feed Bunks

Short Description Goes Here.

You could put a feature highlight of the product here. This could be the most important reason people should choose this product.

This is filler text to show you what your new website will look like with content added. This text will be replaced by the text you provide during the content-adding phase. Most people start with a brief introduction for new website visitors. Hay hook cucumbers. Ewes mushrooms zucchini in forage Harvester at sheep with tractor. Goat goose hen horse. This is filler text to show you what your new website will look like with content added. This text will be replaced by the text you provide during the content-adding phase. Most people start with a brief introduction for new website visitors. Hay hook cucumbers. Ewes mushrooms zucchini in forage Harvester at sheep with tractor. Goat goose hen horse.

Feature
TEXT HERE

2 Year

SYSTEM WARRANTY

Lifetime

WARRANTY ON BALE LOADING ARMS

5 Year

STRUCTURAL WARRANTY

Features

Product Specs Here.

Feature Spec Here.
Feature Spec Here.
Feature Spec Here.
Feature Spec Here.

Product Specs Here.

Feature Spec Here.
Feature Spec Here.
Feature Spec Here.

Features

Since 1983, every Hydra Bed® has been built around this rugged foundation consisting of 6” channel frame long sills and our proven bale handling assembly which features a 1/2” wall rear cross tube rotating on (2) 6” hinge assemblies. These components all work together to provide the structural integrity essential to dependable lifting, hauling and towing. Our dedicated production staff takes great pride in the quality workmanship with which they build this simple, strong, time-tested design.

Power Options

Engine Driven 11 GPM

Cast iron pumping section
Electric clutch engagement
Variable speed controls
11 GPM, at 2,000 engine RPM

Two Stage Electric Over Hydraulic

5.5 GPM at lower pressures
3.7 GPM at higher pressures
Internal thermal protection

Control Options

Your choice of power determines the control options available, allowing you to customize your Hydra Bed to fit your operation.

with Engine Driven Power

Variable speed cables (in cab)
Wireless remote
Corded pendant
Redundant: wireless remote and pendant
Optional third spool auxiliary hydraulics

with Electric Over Hydraulic Power

Wireless remote
Corded pendant
Redundant: wireless remote and pendant
Optional third spool auxiliary hydraulics

Flush-Mount Bale Handler

Six models designed to mount on single or dual wheel 3/4 ton or 1 ton trucks

Unobstructed flatbed functions
4” Square, 1/2” wall rear cross tube
Synchronized arms provide automatic bale centering
Automatic free-float unrolling
Lay-flat alloy unrolling spinners

Trailer
Towing

5th Wheel Hitch

Recessed
Rugged 10” channel mount
30,000# Rated 2 5/16” ball

Rear Drop Hitch

Rugged tubular construction
3/4” thick, 3-hole plate
Optional receiver hitch

Hydraulic Quick Couplers

One Circuit Standard

Provides 11 GPM, 2,500 PSI
Pioneer push-to-connect type

Optional Circuit Available

Managed by the 3rd Spool Auxiliary Controls on your control device, whether it be in-cab cables, wireless remote or corded pendant.
Required for Hydra Feeder™ use

Hydraulic Reservoir

Headache rack mounted
Provides gravity flow to pump
Heavy 3/16” wall thickness
System holds 7 gallons
10 Micron filtration

LED Lighting

All bed lighting is LED, sonically sealed, waterproof, and has a polycarbonate lens and housing.

See it in Action!

Videos or Pictures of Bextra In use could go here.

Hear from our Happy Customers

“This could be a quote from a happy customer.”Happy Bextra Customer

Specifications

[table id=2 /]

[table id=3 /]
